Plate Bending Machine

This plate bending machine, also called plate bending rolls, is suitable to bend the flat colored steel sheet into arc shape sheet. Its bending radius of R=1.8m.
The small-span curing panel, designated profile roof panel, is produced by this roll forming auxiliary equipment. It is strong, durable, and fashionable. This kind of curing panel can save roof purlines and steel frame to lower the cost.

Technical Specification:
1 Size: 950mm × 1200mm × 2500mm
2 Total weights: about1800KG
3 Controlling system: PLC
4 Powers: 3KW
5 Working speed: 1400mm/min

Plate Bending Machine

Main Parameters:
1. Materials Color-coated steel coils / Pre-coated steel coils
2. Profile of Press: C× (0.4~0.8) mm, C is the width of corrugated sheet already produced
3. Thickness: 0.4~0.8mm
4. Width: Max 100~1250mm
5. Speed: Max 15m/min
6. Machine Size: 1000m×900mm×1200mm (Length Width Height)
7. Motor Power: 2.25kw
8. Minimum Diameter: Ф = 1.2m.
9. Speed of Arc Line: L = 13.5m/min.

Yingkou Changsheng Steel Structure Project Co.Ltd is a professional manufacturer and supplier of plate bending machine (plate bender) in China. Apart from auxiliary equipment products, like multifunction window - door taping machine, color coated steel coils, etc. we also offer EPS - rock wool sandwich panel machine like C purlin roll forming machine, Z purlin roll forming machine etc; high pressure polyurethane insulation painting machine including low pressure polyurethane foam machine and high pressure polyurethane foam machine; k-span machine, like automatic building machine, ultimate building machine and arch style buildings forming machine.With good quality and affordable price, the products produced by our company has exported Germany, Holland, India, Indonesia, New Zealand, Syria, United Arab Emirates, Russia, Kuwait, South Africa, and Bangladesh. If you are interested in our products, please contact us for details.
